Hydro-pneumatic Cylinder_HPNG

  • Adjustable Stroke boosting Cylinder
  • HPNG series boosting cylinder could be adjustable stroke to meet different demand. Compare to other cylinders, this cylinder have a reasonable length, suitable installed in the space where can give unlimited room. Well used for stamping, riveting and forming which work at low frequency.

Specification



Motion pattern

Double Action

Pressure range

4-7 kg/cm2 filtered compressed air

Fuel oil

ISO Vg68#

Temperature

-5~80℃ (other temperature can be customized)

operating speed

50~400mm/s

Oil cylinder proof pressure

300 kg/cm2

Air cylinder proof pressure

12 kg/cm2

Stroke tolerance(mm)

+1.0mm  0.0mm

+0.20mm  0.00mm

Working Frequency

20-40 s/min (according to stroke)

How to order
