Compact Cylinder SDA

SDA series compact cylinder design made for the Asian market, the bore from 12mm to 100mm is optional. As to the acting type have double acting, double adjustable acting, single extend acting, single return acting etc. The rod side teeth within conventional-shaped teeth, outer teeth, toothless three kinds of connections. The crash pads buffer types effectively reduce the impact on the cover.

Bore(mm)

100

Working Medium

Filtered compressed Air

Motion Pattern

Double Action Type, Single Acting-push Type, Single Acting-pull Type

Compression Pressure

15 bar

Max. Operating Pressure

Double-acting Type

1~9 bar

Single-acting Type

2~9 bar

Cushion Type

Bumper

Operating Temperature

5~60℃

Operating Speed Range

Double-acting Type

30~500mm/s

30~350mm/s

30-250mm/s

Single-acting Type

100-500mm/s

Joint Pipe Bore

M5*0.8

1/8"

1/4"

3/8"
